170MCI02136
Schneider Electric
Overview
The 170MCI02136 is an I/O Controller in the Modicon Momentum range from Schneider Electric. It executes control logic for Modicon 170 architectures and operates from a 5 V DC supply.
Application & Technical Notes
As an i/o controller, the 170MCI02136 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon 170 equipment is installed. It hosts the application program, executes the control cycle and orchestrates I/O scanning, communication and diagnostics for the station.
Key published characteristics include a 5 V DC rating, an operating temperature range of 0°C to +60°C, din rail or panel mounting. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (0°C to +60°C); do not exceed it during commissioning or in enclosed panels without airflow. For storage and transit, keep the unit within -40°C to +85°C. Back up the application program and parameter set before any firmware or hardware change; verify the memory/real-time-clock battery where fitted and replace on schedule. Monitor the module health LED and controller diagnostics; plan spares for critical stations to minimise downtime. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 170MCI02136, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm the CPU matches your Modicon 170 architecture, memory size, firmware revision and any required option/communication modules. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 170MCI02136?
The 170MCI02136 is an i/o controller in the Modicon Momentum range from Schneider Electric. It is described by the manufacturer as: I/O Controller.
What are the key technical ratings of the 170MCI02136?
Its published highlights include 5 V DC, operating temperature 0°C to +60°C. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the 170MCI02136 mounted or installed?
It uses DIN rail or panel. Follow the manufacturer mounting and torque guidance and observe clearance, grounding and ventilation requirements.
Is the 170MCI02136 compatible with my controller?
It is part of the Modicon 170 family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 170MCI02136?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
Designed for flexibility, the 170MCI02136 I/O Controller by Schneider Electric operates efficiently within the Modicon Momentum series. This controller leverages Modbus Plus communication technology and is powered by a 5 V DC supply.
Specifications
| Product Line | Modicon Momentum |
|---|---|
| Communication | Port Modbus Plus |
| Mounting Type | DIN rail or panel |
| Operating Temperature | 0°C to +60°C |
| Digital | I/O Support Yes |
| Storage Temperature | -40°C to +85°C |
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
