140ACI05100SC
Schneider Electric
Overview
The Schneider Electric 140ACI05100SC is a thirty-two-point input module for the Modicon Quantum series, designed for applications that need high analogue channel density with strong noise immunity. It delivers precision conversion at 12-bit or 16-bit resolution and holds accuracy between ±0.1 % and ±0.2 % of full scale, supporting precise measurement tasks across mixed signal loops.
The module is built for harsh environments: channel-to-channel isolation is typically 500 V DC and channel-to-backplane isolation typically 1500 V DC, helping it survive ground loops and transients on long field wiring. It operates from 0 to 60 °C, tolerates 5–95 % non-condensing humidity, and mounts on DIN rail or panel. At 0.91 kg it is a substantial rack component, and the SC designation denotes a specific configuration within the Quantum input family.
Application & Technical Notes
The 140ACI05100SC targets systems where many analogue points must be concentrated in limited rack space. Selectable 12-bit or 16-bit resolution lets integrators trade speed for precision per application, while ±0.1–0.2 % full-scale accuracy is adequate for most monitoring and supervisory control duties. The differential, well-isolated architecture rejects common-mode interference, which is important when transmitters share different references.
The 500 V DC channel-to-channel and 1500 V DC channel-to-backplane isolation figures are the headline reliability features, reducing the risk of a single fault cascading across the rack. Plan for the module's backplane current and addressing requirements, and confirm the SC configuration matches the intended signal types before ordering.
Maintenance & Diagnostics
The 140ACI05100SC is low-maintenance. Commission by checking channel status and confirming each input is within its expected range before the loop is trusted. Keep the rack within 0–60 °C and 5–95 % non-condensing relative humidity, and ensure ventilation around the module is not blocked.
Because thirty-two points share one module, a single failure removes more signals than a smaller module would, so a spare is advisable for critical systems. De-energise the rack before insertion or removal to protect the backplane, and store spares between −40 and 85 °C in original packaging. Recalibrate quality-critical channels against a known source at planned intervals.
Sourcing & Procurement
The 140ACI05100SC is a high-density Quantum input module; confirm the SC configuration and signal types match your design before purchase. Genuine Schneider Electric modules are recommended for new builds and safety-related loops because they retain the original certifications and warranty. Compatible equivalents may cost less, but verify channel count, isolation and accuracy before substituting.
For long-lead or discontinued parts, refurbished genuine units from a trusted industrial supplier are generally safer than clones. Buy through authorised distributors where possible, validate the seller, and keep the manufacturer part number and serial records for traceability and warranty.
Frequently Asked Questions
What resolution does the 140ACI05100SC offer?
It supports 12-bit or 16-bit resolution, selectable per the application's precision and speed requirements.
How many input points does it provide?
Thirty-two input points, making it a high-density module for the Modicon Quantum platform.
What isolation is provided?
Typically 500 V DC between channels and 1500 V DC channel-to-backplane, helping withstand ground loops and transients.
What is the operating temperature range?
0 to 60 °C, with tolerance for 5–95 % non-condensing relative humidity.
How should it be mounted?
It supports DIN rail or panel mounting within a Quantum rack configuration.
Specifications
The 140ACI05100SC is a 32-point input module from Schneider Electric's Modicon Quantum series. This unit delivers precision in 12-bit or 16-bit resolutions and offers an accuracy range of ±0.1% to ±0.2% of full scale measurements, making it suitable for precise applications.
Description
| Note | Schneider Electric's 140ACI05100SC is an input module designed for high performance within the Modicon Quantum series. It provides the option of a 12-bit or 16-bit resolution to accommodate various applications requiring precision. The stated accuracy of this input module ranges from ±0.1% to ±0.2% of full scale, suited for high-accuracy measurement tasks. Isolation management is exceptionally handled, offering channel-to-channel isolation typically at 500V DC and achieving 1500V DC isolation between the channel and backplane. This ensures reliable operation even in electrically noisy environments. Operating conditions are well-defined, with a temperature range suitable from 0°C to 60°C. For more extreme conditions, the module withstands storage temperatures from -40°C to 85°C. Moisture resistance is also notable, as the device functions efficiently within relative humidity levels of 5% to 95% without condensation. Installation is flexible, allowing for either DIN rail or panel mounting based on user requirements. Weighing only 0.5 kg, this input module is lightweight while delivering solid performance in demanding automation applications. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
