170BNP67100
Schneider Electric
Overview
The 170BNP67100 is a Communication Interface Module in the Modicon Momentum range from Schneider Electric. It extends Modicon 170 connectivity through its onboard communication interface.
Application & Technical Notes
As a communication interface module, the 170BNP67100 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon 170 equipment is installed. It bridges the controller to higher-level networks, HMIs, SCADA and peer devices, carrying configuration, process data and diagnostics.
Key published characteristics include a 5 VDC rating, an operating temperature range of 0°C to +60°C, din rail mounting. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (0°C to +60°C); do not exceed it during commissioning or in enclosed panels without airflow. Confirm network addressing, baud/rate and topology match the rest of the system; keep firmware consistent across the cell. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 170BNP67100, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Match the protocol, connector and topology to the rest of the Modicon 170 network and to the peer devices already installed. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 170BNP67100?
The 170BNP67100 is a communication interface module in the Modicon Momentum range from Schneider Electric. It is described by the manufacturer as: Communication Interface Module.
What are the key technical ratings of the 170BNP67100?
Its published highlights include 5 VDC, operating temperature 0°C to +60°C. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the 170BNP67100 mounted or installed?
It uses DIN Rail. Follow the manufacturer mounting and torque guidance and observe clearance, grounding and ventilation requirements.
Is the 170BNP67100 compatible with my controller?
It is part of the Modicon 170 family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 170BNP67100?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The 170BNP67100 is a communication interface module designed by Schneider Electric for the Modicon Momentum series. This device supports the Modbus Plus protocol and operates with a current draw of 200 mA, ensuring efficient connectivity in industrial environments.
Specifications
| Product Line | Modicon Momentum |
|---|---|
| Status | Indicators LED |
| Connector | Type DB9 Female |
| Compatibility | TSX Momentum I/O |
| Number of | Ports 1 |
| Operating Temperature | 0°C to +60°C |
| Mounting Type | DIN Rail |
| Operating Voltage | 5 VDC |
| Certifications | CE, UL, CSA |
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
