170BDI35400
Schneider Electric
Overview
The 170BDI35400 is a Modicon in the Modicon range from Schneider Electric. It is engineered for industrial automation duties within the Modicon 170 ecosystem.
Application & Technical Notes
As a modicon, the 170BDI35400 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon 170 equipment is installed. It performs a defined automation function within the control system and is selected to match the installed Schneider Electric platform.
Specific electrical and mechanical ratings depend on the exact configuration and suffix of the part; the original datasheet should be consulted for the definitive specification.
Maintenance & Diagnostics
Inspect terminals and connectors for corrosion or looseness, and confirm the module seats correctly in its carrier. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 170BDI35400, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm mechanical and electrical compatibility with your Modicon 170 installation and the intended function. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 170BDI35400?
The 170BDI35400 is a modicon in the Modicon range from Schneider Electric. It is described by the manufacturer as: Modicon.
What are the key technical ratings of the 170BDI35400?
The definitive ratings depend on the exact configuration; consult the original datasheet or the source PDF linked on this page for the complete table.
How is the 170BDI35400 mounted or installed?
Installation follows the standard Modicon 170 mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the 170BDI35400 compatible with my controller?
It is part of the Modicon 170 family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 170BDI35400?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The Schneider Electric 170BDI35400 is a highly functional input module designed for versatility in various automation applications. It supports a voltage supply of 24VDC and accommodates up to 32 input points.
Description
| Note | The 170BDI35400 module from Schneider Electric is designated as an input module within the Modicon series. This module caters to a voltage supply of 24V DC, making it compatible with various control systems. Capable of handling a total of 32 input points, it is ideal for use in automation processes. Built to function efficiently, it has an input resistance value of 4 kOhm. The current consumption remains restricted to 250 mA when supplied with 24 V DC. The module is designed with a discrete input logic in a positive configuration, ensuring accurate signal interpretation. Operating within defined thermal limits, it functions effectively between 0°C to 60°C, proving its reliability in different environmental conditions. The 170BDI35400 module is recognized for meeting CE standards and holds certifications from CSA and UL, demonstrating its adherence to safety and performance regulations. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
