140KRP10000
Schneider Electric
Overview
The 140KRP10000 is a General-purpose I/O module in the Modicon Quantum range from Schneider Electric. It is engineered for industrial automation duties within the Modicon Quantum ecosystem.
Application & Technical Notes
As a general-purpose i/o module, the 140KRP10000 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Quantum equipment is installed. It performs a defined automation function within the control system and is selected to match the installed Schneider Electric platform.
Key published characteristics include a 24 V DC nominal rating, an operating temperature range of -10°C to +60°C. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (-10°C to +60°C); do not exceed it during commissioning or in enclosed panels without airflow. Verify field wiring, shielding and grounding at installation; check terminal torque and confirm signal types match the configured range. Periodically inspect for loose terminations, induced noise and channel-level diagnostics reported by the controller. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 140KRP10000, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm the module matches your Modicon Quantum rack, the required channel count, signal type and voltage, and the firmware/configuration of the controller. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 140KRP10000?
The 140KRP10000 is a general-purpose i/o module in the Modicon Quantum range from Schneider Electric. It is described by the manufacturer as: General-purpose I/O module.
What are the key technical ratings of the 140KRP10000?
Its published highlights include 24 V DC nominal, operating temperature -10°C to +60°C. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the 140KRP10000 mounted or installed?
Installation follows the standard Modicon Quantum mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the 140KRP10000 compatible with my controller?
It is part of the Modicon Quantum family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 140KRP10000?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The 140KRP10000 by Schneider Electric is a versatile general-purpose I/O module designed for use in Modicon Quantum systems. It operates at a nominal voltage of 24 V DC and provides effective input signal processing and management, making it suitable for various industrial applications.
Description
| Note | The Schneider Electric Modicon Quantum 140KRP10000 functions as a general-purpose I/O module that serves a variety of applications in industrial settings. Designed to operate at a nominal voltage of 24 V DC, it possesses input thresholds ranging from 11 V to 30 V DC for ON states and 3 V to 5 V DC for OFF states. This module supports a maximum load of 0.65 A per individual channel, with a cumulative load limit of 10 A across all channels, allowing for efficient current management. The 140KRP10000 features transient protection, with an isolation voltage rated at 500 V, ensuring reliable operation amid voltage spikes. It operates with an update or scan time of approximately 15 milliseconds, contributing to fast signal processing capabilities. The module's bus current requirement falls between 350 mA and 550 mA, which provides essential power supply regulation. Furthermore, it operates effectively within a temperature range of -10°C to +60°C, allowing it to withstand various environmental conditions. For mounting versatility, this module can either be rack-mounted or installed on a DIN rail, which enhances installation flexibility in different setups. Rated with an IP20 protection class, it provides adequate safeguard against foreign objects greater than 12.5 mm in diameter. The 140KRP10000 features integrated signal conditioning, incorporating filtering and surge suppression, which enhances overall system reliability. This module is compatible with the Quantum series and various communication protocols, including Modbus and Profibus. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
