140DVO85300C
Schneider Electric
Overview
The 140DVO85300C is a Discrete Output Module in the Modicon Quantum range from Schneider Electric. It is engineered for industrial automation duties within the Modicon Quantum ecosystem.
Application & Technical Notes
As a discrete output module, the 140DVO85300C is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Quantum equipment is installed. It drives actuators, relays, valves and indicators from controller commands, acting as the actuation layer between logic and the machine.
Key published characteristics include negative logic (sink) signal handling, a 10 to 30 VDC rating. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Verify field wiring, shielding and grounding at installation; check terminal torque and confirm signal types match the configured range. Periodically inspect for loose terminations, induced noise and channel-level diagnostics reported by the controller. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 140DVO85300C, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm the module matches your Modicon Quantum rack, the required channel count, signal type and voltage, and the firmware/configuration of the controller. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 140DVO85300C?
The 140DVO85300C is a discrete output module in the Modicon Quantum range from Schneider Electric. It is described by the manufacturer as: Discrete Output Module.
What are the key technical ratings of the 140DVO85300C?
Its published highlights include 10 to 30 VDC. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the 140DVO85300C mounted or installed?
Installation follows the standard Modicon Quantum mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the 140DVO85300C compatible with my controller?
It is part of the Modicon Quantum family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 140DVO85300C?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The 140DVO85300C, part of Schneider Electric's Modicon Quantum series, is a discrete output module featuring 32 individual output channels. This module operates using negative logic and requires 2 output words along with 2 input words for addressing.
Description
| Note | The 140DVO85300C from Schneider Electric is designated as a discrete output module within the Modicon Quantum series. This component provides 32 output channels that utilize negative logic (sink) for effective control in automation tasks. For addressing purposes, this module necessitates 2 output words along with 2 input words, facilitating communication within the control system. It is capable of operating with an output voltage range of 10 to 30 VDC, responding effectively under various operational conditions. Enhanced functionality is incorporated with integrated short-circuit protection, preventing potential damage during abnormal situations. Additionally, overvoltage protection is also featured, augments the module's durability and reliability. The module supports surge currents of up to 2.5 A, further ensuring performance stability. With a standard format, the module has a compact weight of 0.3 kg, making it easy to incorporate into existing setups. It requires a bus current of 500 mA to function properly. The module remains functional in ambient temperatures varying from 0 °C to 60 °C, thus adapting to diverse environmental settings. Compliance with UL 508 and CSA standards affirms its quality and reliability in industrial applications. The module is marked with CE, ensuring it meets European safety standards. Moreover, it includes conformal coating as a protective treatment to guard against moisture and dust intrusion, reinforcing its longevity in various operational environments. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
