140CPU11304C
Schneider Electric
Overview
The 140CPU11304C is a CPU Module in the Modicon Quantum range from Schneider Electric. It is engineered for industrial automation duties within the Modicon Quantum ecosystem.
Application & Technical Notes
As a cpu module, the 140CPU11304C is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Quantum equipment is installed. It hosts the application program, executes the control cycle and orchestrates I/O scanning, communication and diagnostics for the station.
Key published characteristics include rack-mounted mounting. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Back up the application program and parameter set before any firmware or hardware change; verify the memory/real-time-clock battery where fitted and replace on schedule. Monitor the module health LED and controller diagnostics; plan spares for critical stations to minimise downtime. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 140CPU11304C, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm the CPU matches your Modicon Quantum architecture, memory size, firmware revision and any required option/communication modules. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 140CPU11304C?
The 140CPU11304C is a cpu module in the Modicon Quantum range from Schneider Electric. It is described by the manufacturer as: CPU Module.
What are the key technical ratings of the 140CPU11304C?
The definitive ratings depend on the exact configuration; consult the original datasheet or the source PDF linked on this page for the complete table.
How is the 140CPU11304C mounted or installed?
It uses Rack-mounted. Follow the manufacturer mounting and torque guidance and observe clearance, grounding and ventilation requirements.
Is the 140CPU11304C compatible with my controller?
It is part of the Modicon Quantum family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 140CPU11304C?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The Modicon Quantum 140CPU11304C is a CPU module designed for industrial automation processes. With a robust memory configuration and a communication speed that can reach 1 Mbps, it is suitable for demanding applications.
Description
| Note | The Schneider Electric 140CPU11304C, part of the Modicon Quantum series, is tailored for high-performance control applications. This CPU module operates with an extended memory of 1 MB+ and is equipped with 768 KB of dynamic RAM. Designed to accommodate significant processing requirements, it supports program capacities of up to 16,000 steps. As a rack-mounted unit, it fits seamlessly into existing setups. It includes a single Modbus Plus communication port, facilitating effective automation across different devices. Serial communication capabilities are added through an RS232 port. This module features integrated battery-backed RAM, ensuring that important data is preserved during power outages. The watchdog function is present, contributing to the module's reliability by continuously monitoring system operations. The communication speed maxes out at 1 Mbps, enabling fast data transfer. Programming is seamless with compatible software, which streamline the development process. Local rack support adds to its versatility, making it adaptable within various configurations. Also included are status LEDs that provide real-time feedback on the module's operation, with indicators for run status, fault occurrences, I/O activity, and communication processes. With an execution time of approximately 0.3 microseconds for Boolean operations, the 140CPU11304C stands out for its efficiency in executing logic functions. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
