140CPS11400C
Schneider Electric
Overview
The 140CPS11400C is a Modicon Quantum in the Modicon Quantum range from Schneider Electric. It delivers stable control power at 24 V DC for Modicon Quantum racks.
Application & Technical Notes
As a modicon quantum, the 140CPS11400C is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Quantum equipment is installed. It conditions and distributes the low-voltage supply that powers the controller, I/O and communication modules on the same rack.
Key published characteristics include a 24 V DC rating. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Ensure adequate ventilation and do not overload the supply beyond its published current budget; consider redundancy for critical racks. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 140CPS11400C, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Match the output voltage and current to the Modicon Quantum load and allow headroom for future expansion. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 140CPS11400C?
The 140CPS11400C is a modicon quantum in the Modicon Quantum range from Schneider Electric. It is described by the manufacturer as: Modicon Quantum.
What are the key technical ratings of the 140CPS11400C?
Its published highlights include 24 V DC. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the 140CPS11400C mounted or installed?
Installation follows the standard Modicon Quantum mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the 140CPS11400C compatible with my controller?
It is part of the Modicon Quantum family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 140CPS11400C?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
Designed as a power supply module, the Schneider Electric 140CPS11400C ensures reliable power conversion for Modicon Quantum systems. It accepts an input voltage range of 115 to 230 V AC and operates efficiently at frequencies of 50 or 60 Hz, delivering a stable output of 24 V DC with a current rating of 8 Amperes.
Description
| Note | The 140CPS11400C power supply module produced by Schneider Electric is compatible with Modicon Quantum series setups. It functions by converting input voltages from 115 to 230 Volts AC, supporting both 50 Hz and 60 Hz operational frequencies. The module provides a consistent output at 24 Volts DC while delivering up to 8 Amperes of current, making it suitable for a variety of applications. Featuring a power dissipation capability of 150 watts, this module is designed for efficient power management. In terms of physical size, it measures 120 mm in length, 100 mm in width, and 154 mm in height, which allows for straightforward integration into control panels. With a total weight of 1.5 kg, the module is lightweight yet robust enough for industrial environments. Operating within an ambient temperature range from 0 to 40 degrees Celsius, the 140CPS11400C is built to perform reliably in moderately warm settings. It also caters to humidity conditions, handling operating and storage levels up to 80% Relative Humidity without the risk of condensation significantly affecting performance. Furthermore, this power supply module can be effectively utilized at altitudes reaching 1000 meters, maintaining its specifications without derating, thus ensuring versatile deployment within various locations. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
