140CHS41010
Schneider Electric
Overview
The 140CHS41010 is a Hot Standby Kit in the Modicon Quantum range from Schneider Electric. It is engineered for industrial automation duties within the Modicon Quantum ecosystem.
Application & Technical Notes
As a hot standby kit, the 140CHS41010 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Quantum equipment is installed. It mechanically and electrically unifies the controller, power supply and I/O modules, providing the backplane bus and mounting structure.
Key published characteristics include an operating temperature range of 0 to 40 degrees Celsius. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (0 to 40 degrees Celsius); do not exceed it during commissioning or in enclosed panels without airflow. For storage and transit, keep the unit within 0 to 50 degrees Celsius. Seat every module firmly on the backplane, observe module order where required, and check the bus connector integrity. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 140CHS41010, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm mechanical and electrical compatibility with your Modicon Quantum installation and the intended function. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 140CHS41010?
The 140CHS41010 is a hot standby kit in the Modicon Quantum range from Schneider Electric. It is described by the manufacturer as: Hot Standby Kit.
What are the key technical ratings of the 140CHS41010?
Its published highlights include operating temperature 0 to 40 degrees Celsius. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the 140CHS41010 mounted or installed?
Installation follows the standard Modicon Quantum mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the 140CHS41010 compatible with my controller?
It is part of the Modicon Quantum family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 140CHS41010?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The Schneider Electric 140CHS41010 is a comprehensive hot standby kit designed for system redundancy and reliability within the Modicon Quantum series. This kit includes essential components to facilitate seamless operation in critical applications requiring high availability.
Description
| Note | The 140CHS41010 from Schneider Electric serves as a hot standby kit developed for the Modicon Quantum series. Key components include two Quantum CPUs (140CPU11302) for processing tasks along with two remote I/O processors (140CRP93101) to manage input and output functions effectively. To enhance performance, it is equipped with two 140XBP00600 backplanes, providing the necessary connectivity for various modules. Supporting components like the S908 terminator kit ensure reliable network communication. The assembly features two 140CPS11100 power supplies, enhancing system reliability through redundancy. Two dedicated hot standby processors (140CHS11000) are included to enable seamless transitions in case of a primary unit failure. With a permissible operating temperature range of 0 to 40 degrees Celsius and a storage temperature limit of 0 to 50 degrees Celsius, this kit is suited for a variety of industrial environments. Additionally, the module can operate in locations with humidity levels up to 80% relative humidity without condensation, making it appropriate for demanding conditions. The inclusion of a 3-meter fiber optic hot standby cable helps maintain reliable connections, reinforcing system performance. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
