TSXSUP1011
Schneider Electric
Overview
The TSXSUP1011 is a Power Supply in the TSX Micro PLCs range from Schneider Electric. It delivers stable control power at 24 V DC for the Modicon Premium / TSX racks.
Application & Technical Notes
As a power supply, the TSXSUP1011 is intended for deployment in panel-based control cabinets and machine enclosures where the Modicon Premium / TSX equipment is installed. It conditions and distributes the low-voltage supply that powers the controller, I/O and communication modules on the same rack.
Key published characteristics include a 24 V DC rating, an operating temperature range of 0 to 60°C. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (0 to 60°C); do not exceed it during commissioning or in enclosed panels without airflow. For storage and transit, keep the unit within -25 to 85°C. Ensure adequate ventilation and do not overload the supply beyond its published current budget; consider redundancy for critical racks. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the TSXSUP1011, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Match the output voltage and current to the Modicon Premium / TSX load and allow headroom for future expansion. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Check live stock, lead time and request a quote for TSXSUP1011 (opens in a new tab)
Frequently Asked Questions
What is the TSXSUP1011?
The TSXSUP1011 is a power supply in the TSX Micro PLCs range from Schneider Electric. It is described by the manufacturer as: Power Supply.
What are the key technical ratings of the TSXSUP1011?
Its published highlights include 24 V DC, operating temperature 0 to 60°C. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the TSXSUP1011 mounted or installed?
Installation follows the standard Modicon Premium / TSX mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the TSXSUP1011 compatible with my controller?
It is part of the Modicon Premium / TSX family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the TSXSUP1011?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The Schneider Electric TSXSUP1011 is a versatile power supply belonging to the TSX Micro PLCs series, designed to accommodate various applications. It operates effectively at an input voltage of 24 V AC/DC, supplying a steady output current of 1A while ensuring protection against overload and short circuits.
Description
| Note | The TSXSUP1011 model from Schneider Electric is a power supply specifically crafted for the TSX Micro PLCs series. This unit efficiently accepts input voltage in the form of 24 V AC or DC, providing a stable output of 24 V DC with a maximum output current of 1A. To enhance operational reliability, the power supply is equipped with protection mechanisms against overload and short circuits. The design allows it to function optimally across a temperature range of 0 to 60°C, while it can endure storage temperatures as low as -25°C and up to 85°C. It supports a frequency range of 50/60 Hz for AC inputs, accommodating various installation scenarios. Weighing only 0.5 kg, the power supply is lightweight and ideally suited for DIN rail mounting, facilitating easy installation in various environments. The unit is enclosed in a protective housing, ensuring durability and reliability during operation. Additionally, it features an LED indicator that enables users to monitor the power status effectively. The certification mark of CE underscores its compliance with applicable standards, solidifying its credibility within the industry. The TSXSUP1011 power supply is structured for standalone configuration, offering flexibility in deployment across numerous applications. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
