TSXMBP100
Schneider Electric
Overview
The TSXMBP100 is a PCMCIA card type III in the Modicon Premium Automation platform range from Schneider Electric. It is engineered for industrial automation duties within the Modicon Premium / TSX ecosystem.
Application & Technical Notes
As a pcmcia card type iii, the TSXMBP100 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Premium / TSX equipment is installed. It performs a defined automation function within the control system and is selected to match the installed Schneider Electric platform.
Key published characteristics include an operating temperature range of 0 to 60 °C. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (0 to 60 °C); do not exceed it during commissioning or in enclosed panels without airflow. For storage and transit, keep the unit within -40 to 85 °C. Avoid condensation — the rated humidity is 5 to 95% non-condensing; store and operate the module in a dry, pollution-degree-appropriate enclosure. Inspect terminals and connectors for corrosion or looseness, and confirm the module seats correctly in its carrier. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the TSXMBP100, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm mechanical and electrical compatibility with your Modicon Premium / TSX installation and the intended function. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the TSXMBP100?
The TSXMBP100 is a pcmcia card type iii in the Modicon Premium Automation platform range from Schneider Electric. It is described by the manufacturer as: PCMCIA card type III.
What are the key technical ratings of the TSXMBP100?
Its published highlights include operating temperature 0 to 60 °C. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the TSXMBP100 mounted or installed?
Installation follows the standard Modicon Premium / TSX mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the TSXMBP100 compatible with my controller?
It is part of the Modicon Premium / TSX family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the TSXMBP100?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The TSXMBP100 from Schneider Electric belongs to the TSX Micro PLCs series. This type III PCMCIA card features a 68-pin connector tailored for effective communication and data management in automation systems.
Description
| Note | The TSXMBP100 is a PCMCIA card type III developed by Schneider Electric, specifically intended for use within the TSX Micro PLC series. It incorporates a 68-pin connector that ensures reliable interfacing with other components in a control system. Operating data can be transferred at 1 Mbps, facilitating efficient communication. This card is engineered to endure various industrial conditions. It features a vibration resistance of 1.5 mm peak to peak within a range of 3 to 13 Hz and can withstand a 1 g force from 13 to 150 Hz. The device's shock tolerance is rated at 15 g for a duration of 11 ms, ensuring stability under dynamic conditions. Operating humidity levels from 5% to 95% (non-condensing) are permissible, confirming its adaptability in different environmental settings. From a temperature perspective, the TSXMBP100 functions optimally at temperatures ranging from 0 to 60 °C. When stored, it can maintain integrity between -40 °C and 85 °C. This unit weighs 0.11 kg and has compact dimensions of 3.5 x 15.5 x 17 mm, making it convenient for integrating various systems. This card demonstrates efficient power management during operation with a current draw of 220 mA at a 5 V DC supply. Its compatibility extends to notable devices like the Premium processor TSX 57 (versions 1 through 5) and Atrium slot-PLC T PCX/TSX PCI (versions 2 and 3). The card also includes LED indicators for immediate status feedback, enhancing usability in monitoring applications. |
|---|---|
| Range of Product | Modicon Premium Automation platform |
| Accessory / separate part category | Communication accessories Accessory / Separate Part Type PCMCIA card Accessory / separate part destination Magelis XBT F terminals Premium processor TSX 57 1./2./3./4./5. Atrium slot-PLC T PCX/TSX PCI 57 2./3. |
Complementary
| Note | Memory type PCMCIA card type III Communication Port Protocol Modbus Plus |
|---|---|
| Current consumption | 220 mA 5 V DC |
| Net Weight | 0.24 lb(US) (0.11 kg) |
Ordering and shipping details
| Category | US1PC2222558 |
|---|---|
| Discount Schedule | PC22 GTIN 3389110843118 |
| Returnability | No |
Packing Units
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 1.4 in (3.5 cm) |
| Package 1 Width | 6.1 in (15.5 cm) |
| Package 1 Length | 6.7 in (17.0 cm) |
| Package weight(Lbs) | 7.3 oz (206.0 g) |
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
