TSXETG100
Schneider Electric
Overview
The TSXETG100 is an Ethernet Modbus gateway/router in the ConneXium range from Schneider Electric. It extends Modicon Premium / TSX connectivity through its onboard communication interface.
Application & Technical Notes
As an ethernet modbus gateway/router, the TSXETG100 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Premium / TSX equipment is installed. It bridges the controller to higher-level networks, HMIs, SCADA and peer devices, carrying configuration, process data and diagnostics.
Key published characteristics include a 24 V DC rating, an operating temperature range of 32…140 °F (0…60 °C), symmetrical din rail mounting. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (32…140 °F (0…60 °C)); do not exceed it during commissioning or in enclosed panels without airflow. Avoid condensation — the rated humidity is 5-95 % at 104 °F (40 °C) without condensation; store and operate the module in a dry, pollution-degree-appropriate enclosure. Confirm network addressing, baud/rate and topology match the rest of the system; keep firmware consistent across the cell. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the TSXETG100, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Match the protocol, connector and topology to the rest of the Modicon Premium / TSX network and to the peer devices already installed. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the TSXETG100?
The TSXETG100 is an ethernet modbus gateway/router in the ConneXium range from Schneider Electric. It is described by the manufacturer as: Ethernet Modbus gateway/router.
What are the key technical ratings of the TSXETG100?
Its published highlights include 24 V DC, operating temperature 32…140 °F (0…60 °C). Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the TSXETG100 mounted or installed?
It uses Symmetrical DIN rail. Follow the manufacturer mounting and torque guidance and observe clearance, grounding and ventilation requirements.
Is the TSXETG100 compatible with my controller?
It is part of the Modicon Premium / TSX family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the TSXETG100?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The TSXETG100 module is a part of Schneider Electric's TSX Micro PLCs series. It operates with a rated supply voltage of 24 V DC and supports several Ethernet protocols, including Modbus TCP/IP and HTTP. The unit also facilitates serial communication through Modbus RTU and ASCII protocols, enabling flexible connectivity options for industrial applications.
Complementary
| Web services | Via predefined web pages : diagnostic on Ethernet and Modbus links Predefined web pages Access to connected products list, reading of Modbus devices registers |
|---|---|
| Communication Service | SNMP agent, device administration with a SNMP manager Read/write Modbus registers of connected devices Miniature firewall on-board (IP address filtering) and password protection BOOTP protocol, FDR client |
| Supply | Power supply device PoE IEEE 802.3af |
| Integrated connection type | Ethernet TCP/IP RJ45 10/100 Mbps 1 twisted pair Serial link 5-way removable terminal block Modbus RTU and ASCII RS485 57.6 kbps Serial link micro switches Modbus RTU and ASCII RS485 57.6 kbps Serial link RJ45 RS232 38.4 kbps Maximum Number of Connected Devices Modbus serial link: 32 |
| Port Ethernet | 10BASE-T/100BASE-TX Mounting Support Symmetrical DIN rail |
| Marking | CE |
| Local signalling | 3 LEDs for serial link communication (RS485, RX, TX) 4 LEDs for Ethernet communication (LK, RX, TX, 100) |
| Width | 2.8 in (72 mm) |
| Height | 3.2 in (81 mm) |
| Depth | 3.0 in (76 mm) |
Environment
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
|---|---|
| Relative humidity | 5…95 % 104 °F (40 °C) without condensation |
| IP Degree of Protection | IP30 |
| Standards | EN 61000-4-2/3/4/5/6/8 UL 508 CSA C22.2 No 14-M91 EN 55022 FCC class A EN 61000-6-2 |
| Product Certifications | cUL UL |
Ordering and shipping details
| Category | 18225-PLC NTWRK HRDWR & PROWORX SOFTWARE |
|---|---|
| Discount Schedule | PC41 GTIN 00785901524939 |
| Returnability | No |
| Country of origin | IN |
Packing Units
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
Description
| Note | The Schneider Electric TSXETG100 is an efficient communication module within the TSX Micro PLCs lineup. It utilizes a 24-V DC-rated supply voltage, which is integral to its operation. Users can leverage various Ethernet protocols, including Modbus TCP/IP, HTTP, FTP, SNMP, and ARP, allowing for robust networking capabilities. In addition to Ethernet functionalities, the module supports serial communication with protocols, including Modbus RTU and ASCII. It features an RJ45 Ethernet connection type capable of 10/100 Mbps speeds. Serially, connections can be established utilizing RS485 at 57.6 kbps or RS232 at 38.4 kbps. The unit is designed to support less than 32 devices connected through its Modbus serial link, offering significant versatility for different configurations. Mounting with symmetrical DIN rail support is straightforward, ensuring a secure and efficient installation. Local signaling on the TSXETG100 includes three LEDs for serial communication and four LEDs dedicated to Ethernet communication, facilitating real-time diagnostics and monitoring. The TSXETG100's physical dimensions are 72 x 81 x 76 mm, making it compact enough for various deployment scenarios. The module operates effectively within a temperature range of 32 to 140 °F (0 to 60 °C) and maintains performance in relative humidity levels from 5% to 95% at the upper-temperature limit, provided that condensation is absent. It has an IP30 degree of protection, shielding it from dust and accidental contact with solid objects. The TSXETG100 complies with several industry standards, including EN 61000-4, UL 508, and FCC class A, ensuring reliability and safety within industrial applications. Additionally, it holds cUL and UL product certifications, validating its adherence to critical safety standards. Web services allow diagnostic capabilities over Ethernet and Modbus links, simplified via predefined web pages, enhancing usability and troubleshooting. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
