TM5SBER2
Schneider Electric
Overview
The TM5SBER2 is a Remote receiver module in the Modicon TM5 range from Schneider Electric. It is engineered for industrial automation duties within the Modicon TM logic controller / I/O ecosystem.
Application & Technical Notes
As a remote receiver module, the TM5SBER2 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon TM logic controller / I/O equipment is installed. It localises I/O close to the field devices, reducing wiring length and bringing intelligence to the periphery of the installation.
Specific electrical and mechanical ratings depend on the exact configuration and suffix of the part; the original datasheet should be consulted for the definitive specification.
Maintenance & Diagnostics
For storage and transit, keep the unit within -13…158 °F (-25…70 °C). Avoid condensation — the rated humidity is 5…95 % without condensation; store and operate the module in a dry, pollution-degree-appropriate enclosure. Verify field wiring, shielding and grounding at installation; check terminal torque and confirm signal types match the configured range. Periodically inspect for loose terminations, induced noise and channel-level diagnostics reported by the controller. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the TM5SBER2, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm the module matches your Modicon TM logic controller / I/O rack, the required channel count, signal type and voltage, and the firmware/configuration of the controller. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the TM5SBER2?
The TM5SBER2 is a remote receiver module in the Modicon TM5 range from Schneider Electric. It is described by the manufacturer as: Remote receiver module.
What are the key technical ratings of the TM5SBER2?
The definitive ratings depend on the exact configuration; consult the original datasheet or the source PDF linked on this page for the complete table.
How is the TM5SBER2 mounted or installed?
Installation follows the standard Modicon TM logic controller / I/O mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the TM5SBER2 compatible with my controller?
It is part of the Modicon TM logic controller / I/O family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the TM5SBER2?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
TM5SBER2 | Schneider Electric | Remote receiver module, Modicon TM5, Communication between RIO, Distribute power
Complementary
| Note | Range Compatibility :Modicon M258 | Modicon LMC058 Product Compatibility :Logic controller | Motion controller Color :Gray Bus length :8202.10 ft (2500 m) Maximum cable distance between devices :328.08 ft (100 m) Current consumption :25 mA 24 V DC input/output Maximum power dissipation in W :2.22 W Local signalling :1 LED green power supply | 1 LED red power bus current |1 LED red power supply | 1 LED yellow communication data bus Marking :CE Product Weight :0.06 lb(US) (0.025 kg) |
|---|
Environment
| Note | Standards :CSA C22.2 No 142 | CSA C22.2 No 213 | IEC 61131-2 | UL 508 Product Certifications :CSA | cULus | C-tick | GOST-R Ambient air temperature for operation :32…122 °F (0…50 °C) vertical installation) | 32…131 °F (0…55 °C) without derating horizontal installation) | 32…140 °F (0…60 °C) with derating factor horizontal installation) Ambient Air Temperature for Storage : -13…158 °F (-25…70 °C) Relative Humidity : 5…95 % without condensation IP degree of protection :IP20IEC 61131-2 | IP67 Pollution degree :2 IEC 60664 Operating altitude :0...6561.68 ft (0...2000 m) Storage altitude :0.00…9842.52 ft (0…3000 m) Vibration resistance :1 gn 8.4…150 Hz DIN rail | 3.5 mm 5…8.4 Hz DIN rail Shock resistance :15 gn 11 ms Resistance to electrostatic discharge :4 kV on contact EN/IEC 61000-4-2 | 8 kV in air EN/IEC 61000-4-2 Resistance to electromagnetic fields :0.91 V/m (1 V/m) 2...2.7 GHz EN/IEC 61000-4-3 | 9.14 V/m (10 V/m) 80...2000 MHz EN/IEC 61000-4-3 Resistance to fast transients :1 kV EN/IEC 61000-4-4 I/O) | 1 kV EN/IEC 61000-4-4 shielded cable) | 2 kV EN/IEC 61000-4-4 power lines) Surge withstand :0.5 kV differential mode EN/IEC 61000-4-5 | 1 kV common mode EN/IEC 61000-4-5 Electromagnetic compatibility :EN/IEC 61000-4-6 Disturbance radiated/conducted :CISPR 11 |
|---|
Ordering and shipping details
| Note | Category :22532-M258 PLC Discount Schedule :PC12 GTIN :3595864074870 Returnability :No Country of origin :AT |
|---|
Packing Units
| Note | Unit Type of Package 1 :PCE Number of Units in Package 1 :1 Package 1 Height :1.18 in (3.000 cm) Package 1 Width :2.36 in (6.000 cm) Package 1 Length :4.13 in (10.500 cm) Package 1 Weight :2.12 oz (60.000 g) |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
