TM2DDI8DT
Schneider Electric
Overview
The TM2DDI8DT is a Discrete input module in the Modicon M238 logic controller range from Schneider Electric. It executes control logic for Modicon TM logic controller / I/O architectures and operates from a limits 20.4...28.8 V supply.
Application & Technical Notes
As a discrete input module, the TM2DDI8DT is intended for deployment in panel-based control cabinets and machine enclosures where Modicon TM logic controller / I/O equipment is installed. It hosts the application program, executes the control cycle and orchestrates I/O scanning, communication and diagnostics for the station.
Key published characteristics include a limits 20.4...28.8 V rating, 35 mm symmetrical din rail mounting. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Back up the application program and parameter set before any firmware or hardware change; verify the memory/real-time-clock battery where fitted and replace on schedule. Monitor the module health LED and controller diagnostics; plan spares for critical stations to minimise downtime. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the TM2DDI8DT, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm the CPU matches your Modicon TM logic controller / I/O architecture, memory size, firmware revision and any required option/communication modules. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the TM2DDI8DT?
The TM2DDI8DT is a discrete input module in the Modicon M238 logic controller range from Schneider Electric. It is described by the manufacturer as: Discrete input module.
What are the key technical ratings of the TM2DDI8DT?
Its published highlights include limits 20.4...28.8 V. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the TM2DDI8DT mounted or installed?
It uses 35 mm symmetrical DIN rail. Follow the manufacturer mounting and torque guidance and observe clearance, grounding and ventilation requirements.
Is the TM2DDI8DT compatible with my controller?
It is part of the Modicon TM logic controller / I/O family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the TM2DDI8DT?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
TM2DDI8DT Schneider Electric TM2DDI8DT Schneider Electric
Main
| Range of product Modicon M238 logic controller | Product or component type Discrete input module Discrete input number 8 |
|---|---|
| Discrete input voltage 24 V | Discrete input voltage type DC |
Complementary
| Range compatibility Advantys OTB | Twido Input voltage limits 20.4...28.8 V |
|---|---|
| Discrete input logic Sink or source | Discrete input current 7 mA Input impedance 3.4 kOhm Number of common point 1 Response time 4 ms at state 0 4 ms at state 1 Isolation between channels None Isolation between channels and internal logic 500 V for 1 minute Current consumption 25 mA 5 V DC at state 1 for all input Local signalling 1 display block Electrical connection 1 removable screw terminal block Mounting support 35 mm symmetrical DIN rail Product weight 0.22 lb(US) (0.1 kg) |
Environment
| Note | depth 3.33 in (84.6 mm) height 3.54 in (90 mm) width 0.93 in (23.5 mm) |
|---|
Offer Sustainability
| Note | Green Premium product Green Premium product Compliant - since 1039 - Schneider Electric declaration of conformity Compliant - since 1039 - Schneider Electric declaration of conformity Reference not containing SVHC above the threshold Reference not containing SVHC above the threshold Available Available Available Available |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
