STBACI1230K
Schneider Electric
Overview
The STBACI1230K is a Standard analog input kit in the Modicon STB distributed I/O solution range from Schneider Electric. It provides 2 channels and is built for signal interfacing within Advantys STB distributed I/O systems.
Application & Technical Notes
As a standard analog input kit, the STBACI1230K is intended for deployment in panel-based control cabinets and machine enclosures where Advantys STB distributed I/O equipment is installed. It converts field signals (sensors, switches, transmitters) into the digital or analogue values the controller processes, forming the acquisition layer of the automation scheme.
Key published characteristics include 2 channels, an operating temperature range of -25...70 °C. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (-25...70 °C); do not exceed it during commissioning or in enclosed panels without airflow. For storage and transit, keep the unit within -40...85 °C without derating. Avoid condensation — the rated humidity is 95 % 60 °C without condensation; store and operate the module in a dry, pollution-degree-appropriate enclosure. Verify field wiring, shielding and grounding at installation; check terminal torque and confirm signal types match the configured range. Periodically inspect for loose terminations, induced noise and channel-level diagnostics reported by the controller. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the STBACI1230K, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm the module matches your Advantys STB distributed I/O rack, the required channel count, signal type and voltage, and the firmware/configuration of the controller. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the STBACI1230K?
The STBACI1230K is a standard analog input kit in the Modicon STB distributed I/O solution range from Schneider Electric. It is described by the manufacturer as: Standard analog input kit.
What are the key technical ratings of the STBACI1230K?
Its published highlights include 2 channels, operating temperature -25...70 °C. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the STBACI1230K mounted or installed?
Installation follows the standard Advantys STB distributed I/O mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the STBACI1230K compatible with my controller?
It is part of the Advantys STB distributed I/O family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the STBACI1230K?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
Schneider Electric STBACI1230K
Main
| Range of product Modicon STB distributed I/O solution | Product or component type Standard analog input kit Kit composition STBACI1230 module STBXBA1000 base STBXTS1100, 6-terminal screw type connector STBXTS2100, 6-terminal spring clamp connector Analogue input type Current 0...20 mA Analogue input number 2 Analogue input resolution 12 bits Type of filter Single low pass input filter 25 Hz |
|---|
Complementary
| Note | Absolute maximum input 25 mA/50 V DC Response time 5 ms |
|---|---|
| Cold swapping Yes | Hot swapping fallback Yes for standard NIMs Fallback status State 0 basic NIMs User configurable standard NIMs Data format EN 61131-2 IEC 61131-2 Update time 10 ms Integral linearity +/- 0.1 %FS Differential linearity Monotonic Input impedance <= 300 Ohm Supply current for sensors 100 mA per input channels Protection type Short-circuit protection Absolute accuracy error +/- 0.5 % of full scale 25 °C Temperature drift +/-0.01 %/°C Insulation between channels and logic bus 1500 V for 1 minute Insulation between channels and sensor bus 30 V Addressing requirement 4 input words Product compatibility Mounting base STBXBA1000 |
| Power distribution module STBPDT3100/3105 | [Us] rated supply voltage 24 V DC |
| Supply Power distribution module | Current consumption 30 mA 5 V DC logic bus |
| Marking CE | Overvoltage category II Status LED 1 LED green module status (RDY) 1 LED red module error (ERR) Depth 70 mm Height 13.9 mm Width 128.3 mm Product weight 0.116 kg |
Environment
| Note | Product certifications ATEX Cat 3G CSA |
|---|---|
| C-Tick | FM Class 1 Division 2 UL Pollution degree 2 IEC 60664-1 Operating altitude <= 2000 m IP degree of protection IP20 EN 61131-2 class 1 Ambient air temperature for operation -25...70 °C Ambient air temperature for operation 32...140 °F without derating Ambient air temperature for storage -40...85 °C without derating Ambient air temperature for storage -40...185 °F without derating Relative humidity 95 % 60 °C without condensation Vibration resistance +/-0.35 mm 10...58 Hz 3 gn 58...150 Hz 35 x 7.5 mm symmetrical DIN rail 5 gn 58...150 Hz 35 x 15 mm symmetrical DIN rail Shock resistance 30 gn 11 ms IEC 88 reference 2-27 |
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
