DR-1030-000
Schneider Electric
Overview
The DR-1030-000 is a Modicon in the Modicon range from Schneider Electric. It is engineered for industrial automation duties within the the Schneider Electric automation portfolio ecosystem.
Application & Technical Notes
As a modicon, the DR-1030-000 is intended for deployment in panel-based control cabinets and machine enclosures where the Schneider Electric automation portfolio equipment is installed. It performs a defined automation function within the control system and is selected to match the installed Schneider Electric platform.
Key published characteristics include a Range 240-480 VAC rating, an operating temperature range of -10 to 50 degrees Celsius. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (-10 to 50 degrees Celsius); do not exceed it during commissioning or in enclosed panels without airflow. Avoid condensation — the rated humidity is Range 0 to 90% Non-condensing; store and operate the module in a dry, pollution-degree-appropriate enclosure. Inspect terminals and connectors for corrosion or looseness, and confirm the module seats correctly in its carrier. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the DR-1030-000, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm mechanical and electrical compatibility with your the Schneider Electric automation portfolio installation and the intended function. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the DR-1030-000?
The DR-1030-000 is a modicon in the Modicon range from Schneider Electric. It is described by the manufacturer as: Modicon.
What are the key technical ratings of the DR-1030-000?
Its published highlights include Range 240-480 VAC, operating temperature -10 to 50 degrees Celsius. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the DR-1030-000 mounted or installed?
Installation follows the standard the Schneider Electric automation portfolio mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the DR-1030-000 compatible with my controller?
It is part of the the Schneider Electric automation portfolio family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the DR-1030-000?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The DR-1030-000 part from Schneider Electric's Modicon series is designed as a servo drive, operating effectively in various industrial scenarios. It supports a rated voltage of 325V DC with a maximum current capacity of 30 Amps and an input voltage range of 240 to 480 VAC, making it versatile for different applications.
Description
| Note | Designed by Schneider Electric, the DR-1030-000 servo drive represents a crucial component in motion control systems. Operating at a nominal voltage of 325 V DC, it is suitable for a wide variety of applications. This unit can handle a peak current of 30 amps and supports an input voltage range spanning from 240 to 480 VAC, highlighting its flexibility. The control method employed in this device is vector control, which provides precise control of speed and torque characteristics of connected motors. Feedback is managed via an incremental encoder, achieving a resolution of up to 20 bits, ensuring accurate position sensing for dynamic applications. For communication, the drive features multiple interfaces, including RS232, RS485, and CANopen, facilitating straightforward integration with other systems. Operating effectively in ambient conditions, the temperature range for this drive is set between -10 to 50 degrees Celsius. Furthermore, it can function in environments with relative humidity levels ranging from 0 to 90%, provided they are non-condensing. Rated with a protection class of IP20, the DR-1030-000 is designed for indoor applications, protecting internal components from dust and other objects. It weighs around 5.5 kilograms, making installation and maintenance manageable. The control signal input is specified at ±10 (±5%), and users can configure up to 8 digital inputs for varied control options. Additionally, the switching frequency can be adjusted between 2 kHz to 16 kHz, enabling tailored performance based on application requirements. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
