AS-BDEP-210
Schneider Electric
Overview
The AS-BDEP-210 is a Modicon in the Modicon range from Schneider Electric. It is engineered for industrial automation duties within the the Schneider Electric automation portfolio ecosystem.
Application & Technical Notes
As a modicon, the AS-BDEP-210 is intended for deployment in panel-based control cabinets and machine enclosures where the Schneider Electric automation portfolio equipment is installed. It performs a defined automation function within the control system and is selected to match the installed Schneider Electric platform.
Key published characteristics include a 120 VAC rating. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Inspect terminals and connectors for corrosion or looseness, and confirm the module seats correctly in its carrier. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the AS-BDEP-210, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm mechanical and electrical compatibility with your the Schneider Electric automation portfolio installation and the intended function. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the AS-BDEP-210?
The AS-BDEP-210 is a modicon in the Modicon range from Schneider Electric. It is described by the manufacturer as: Modicon.
What are the key technical ratings of the AS-BDEP-210?
Its published highlights include 120 VAC. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the AS-BDEP-210 mounted or installed?
Installation follows the standard the Schneider Electric automation portfolio mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the AS-BDEP-210 compatible with my controller?
It is part of the the Schneider Electric automation portfolio family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the AS-BDEP-210?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The AS-BDEP-210 is a discrete input module from Schneider Electric's Modicon series, designed to handle 8 input points. This module operates at an input voltage of 120 VAC and supports frequencies of 50/60 Hz.
Description
| Note | The AS-BDEP-210 discrete input module by Schneider Electric is specifically tailored for MODICON applications. It accommodates up to 8 input points, making it suitable for various control tasks. Operating under an input voltage of 120 VAC, it provides reliable performance across a frequency range of 50 to 60 Hz. This module boasts a compact design which is beneficial for limited space installations. It weighs 0.27 kg (equivalent to 0.6 lbs), facilitating easy handling and installation. Dimensions of the product reach 180 mm in length, 160 mm in width, and 211 mm in height, or 7.1 x 6.3 x 8.3 inches when converted to imperial measurements. The AS-BDEP-210 module also incorporates isolation features to minimize interference and ensure stability in operation. Overall, this discrete input module is engineered to meet the needs of various industrial control systems with efficiency and reliability. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
