ABL8RPS24100
Schneider Electric
Overview
The ABL8RPS24100 is a Power supply in the Modicon Power Supply range from Schneider Electric. It delivers stable control power at 24 V DC for the Schneider Electric automation portfolio racks.
Application & Technical Notes
As a power supply, the ABL8RPS24100 is intended for deployment in panel-based control cabinets and machine enclosures where the Schneider Electric automation portfolio equipment is installed. It conditions and distributes the low-voltage supply that powers the controller, I/O and communication modules on the same rack.
Key published characteristics include a 24 V DC rating, 35 x 7.5 mm symmetrical din rail mounting. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Ensure adequate ventilation and do not overload the supply beyond its published current budget; consider redundancy for critical racks. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the ABL8RPS24100, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Match the output voltage and current to the the Schneider Electric automation portfolio load and allow headroom for future expansion. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the ABL8RPS24100?
The ABL8RPS24100 is a power supply in the Modicon Power Supply range from Schneider Electric. It is described by the manufacturer as: Power supply.
What are the key technical ratings of the ABL8RPS24100?
Its published highlights include 24 V DC. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the ABL8RPS24100 mounted or installed?
It uses 35 x 7.5 mm symmetrical DIN rail. Follow the manufacturer mounting and torque guidance and observe clearance, grounding and ventilation requirements.
Is the ABL8RPS24100 compatible with my controller?
It is part of the the Schneider Electric automation portfolio family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the ABL8RPS24100?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The ABL8RPS24100 by Schneider Electric is a versatile universal power supply designed for adaptability in various applications. It features a regulated switch mode power supply that delivers consistent output.
Description
| Note | The Schneider Electric ABL8RPS24100 universal power supply module operates under regulated switch mode technology, ensuring stable power for connected devices. It accommodates a nominal input voltage between 100 and 120 V AC for single-phase configurations, while also supporting a range of 200 to 500 V AC from phase to phase. The power supply has input voltage limits, allowing operation between 170 and 550 V AC or 85 to 132 V AC. Providing a power rating of up to 240 Watts, this unit offers an output of 24 V DC at a current capacity of 10 A. The initial inrush current is rated at 30 A, allowing for brief surges during operation. The power factor is measured at 0.68 when powered by 240 V AC, and at 0.69 when running with 120 V AC. In terms of efficiency, the power dissipation of the module is specified at 31 W. The unit is compact, weighing approximately 1 kg, with dimensions of 145 mm in depth, 125 mm in height, and 86 mm in width. This configuration makes the ABL8RPS24100 suitable for a variety of installations where reliable power supply is essential. |
|---|---|
| Range of Product | Modicon Power Supply Product or Component Type Power supply Power supply type Regulated switch mode Nominal input voltage 100...120 V AC single phase N-L1 200...500 V AC phase to phase L1-L2 Rated power in W 240 W |
| Output voltage | 24 V DC |
| Power supply output current | 10 A Permissible temporary current boost 1.5 x In for 4 s) Anti-harmonic filter Low frequency harmonic currents |
Complementary
| Note | Efficiency at full load 170...550 V AC 85...132 V AC |
|---|---|
| Inrush current | 30 A Power factor 0.68 at 240 V AC 0.69 at 120 V AC Efficiency 87 % Output voltage adjustment 24...28.8 V adjustable |
| Power dissipation in W | 31 W Provided equipment Power factor correction filter IEC 61000-3-2 Output protection type Against overload, protection technology: manual or automatic reset Against overvoltage, protection technology: 30...32 V, manual reset Against short-circuits, protection technology: manual or automatic reset Against undervoltage, protection technology: tripping if U < 21.6 V Thermal, protection technology: automatic reset Connections - terminals Removable screw terminal block 2 x 2.5 mm², diagnostic relay Screw type terminals 3 x 0.5...3 x 4 mm², AWG 22...AWG 12) input connection Screw type terminals 1 x 0.5...1 x 4 mm², AWG 22...AWG 12) input ground connection Screw type terminals 4 x 0.5...4 x 4 mm², AWG 22...AWG 12) output connection Screw type terminals 1 x 0.5...1 x 4 mm², AWG 22...AWG 12) output ground connection |
| Status LED | 1 LED (green and red) output voltage 1 LED (green, red and orange) output current |
| Depth | 5.7 in (145 mm) |
| Height | 4.9 in (125 mm) |
| Width | 3.4 in (86 mm) |
| Net Weight | 2.2 lb(US) (1 kg) Output coupling Parallel Series |
| Marking | CE Mounting support 35 x 7.5 mm symmetrical DIN rail 35 x 15 mm symmetrical DIN rail |
| Operating position | Vertical |
| Supply | SELV IEC 60950-1 SELV IEC 60204-1 SELV IEC 60364-4-41 |
| Dielectric strength | 3500 V with between input and ground 4000 V with between input and output 500 V with between output and ground |
Environment
| Standards | UL 508 CSA C22.2 No 60950-1 EN/IEC 62368-1 |
|---|---|
| Product certifications | CCSAus EAC KC RCM UL |
| Environmental characteristic | EMC conforming to IEC 61000-6-1 EMC conforming to IEC 61000-6-3 EMC conforming to EN 55024 EMC conforming to IEC 61000-6-4 EMC conforming to EN/IEC 61204-3 Safety conforming to IEC 60950-1 Safety conforming to EN/IEC 61204-3 |
| Operating altitude | 6561.68 ft (2000 m) |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Ambient air temperature for operation | 122…140 °F (50…60 °C) with derating factor mounting position A < 6561.68 ft (2000 m) -13…122 °F (-25…50 °C) without derating mounting position A < 6561.68 ft (2000 m) |
