ABFM32H300
Schneider Electric
Overview
The ABFM32H300 is a Cabled connector in the Modicon Quantum range from Schneider Electric. It is engineered for industrial automation duties within the Modicon Quantum ecosystem.
Application & Technical Notes
As a cabled connector, the ABFM32H300 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Quantum equipment is installed. It performs a defined automation function within the control system and is selected to match the installed Schneider Electric platform.
Key published characteristics include an operating temperature range of –20 °C to +60 °C. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (–20 °C to +60 °C); do not exceed it during commissioning or in enclosed panels without airflow. Inspect terminals and connectors for corrosion or looseness, and confirm the module seats correctly in its carrier. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the ABFM32H300, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm mechanical and electrical compatibility with your Modicon Quantum installation and the intended function. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the ABFM32H300?
The ABFM32H300 is a cabled connector in the Modicon Quantum range from Schneider Electric. It is described by the manufacturer as: Cabled connector.
What are the key technical ratings of the ABFM32H300?
Its published highlights include operating temperature –20 °C to +60 °C. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the ABFM32H300 mounted or installed?
Installation follows the standard Modicon Quantum mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the ABFM32H300 compatible with my controller?
It is part of the Modicon Quantum family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the ABFM32H300?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The ABFM32H300 from Schneider Electric is a connector designed for reliable communication in Modicon Quantum systems. With 32 channels and a robust design, it supports relay I/O signaling, ensuring effective operational functionality.
Description
| Note | Schneider Electric offers the ABFM32H300 as part of its Modicon Quantum series. This cabled connector excels in providing 32 channels that facilitate relay I/O signals. It comes with a substantial cable length of 9.8 feet (3 meters), ideal for various industrial applications. The electrical setup includes two connectors, each with an AWG gauge of 22, which enables robust connections suitable for multiple devices. The wire section measures 0.324 mm² to accommodate the required current flow efficiently. Designed to function in a range of environmental conditions, the operating temperature for this connector spans from –20 °C to +60 °C. Channel splitting capability enhances its functionality by allowing the division into two sets of 16 channels, which adds versatility for system configurations. This cabled connector is constructed from multi-conductor shielded cable, providing excellent protection from electromagnetic interference. Weighing 1.15 kg, the ABFM32H300 is rated for a current of 2A and supports a voltage of up to 250 V, ensuring it meets the electrical demands of varied applications. With its reliable design and specifications, this connector is an essential component for systems requiring effective relay signaling and connectivity. |
|---|---|
| Range of Product | Modicon Quantum Accessory / separate part designation Cabled connector Accessory / Separate Part Type Connector |
| Accessory / separate part category | Connection accessories Accessory / separate part destination Modicon Quantum PLC |
| Number of Channels | 32 |
Complementary
| Note | Cable length 9.8 ft (3 m) |
|---|---|
| Type of signal | Relay I/O |
| Electrical Connection | 2 connectors |
| Connector Type | HE10 |
| Number of ways | 20 ways |
| Wire section | 0.0005 in² (0.324 mm²) |
| AWG Gauge | AWG 22 Channel splitting 2 x 16 |
| Net Weight | 2.54 lb(US) (1.15 kg) |
Ordering and shipping details
| Category | US10CP222375 |
|---|---|
| Discount Schedule | 0CP2 GTIN 3389110705348 |
| Returnability | No |
| Country of origin | FR |
Packing Units
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 3.031 in (7.700 cm) |
| Package 1 Width | 11.654 in (29.600 cm) |
| Package 1 Length | 8.465 in (21.500 cm) |
| Package weight(Lbs) | 2.833 lb(US) (1.285 kg) |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 8 |
| Package 2 Height | 11.811 in (30.000 cm) |
| Package 2 Width | 15.748 in (40.000 cm) |
| Package 2 Length | 23.622 in (60.000 cm) |
| Package 2 Weight | 23.695 lb(US) (10.748 kg) |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 32 |
| Package 3 Height | 29.528 in (75.000 cm) |
| Package 3 Width | 23.622 in (60.000 cm) |
| Package 3 Length | 31.496 in (80.000 cm) |
| Package 3 Weight | 120.434 lb(US) (54.628 kg) |
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
