ABFM16S201
Schneider Electric
Overview
The ABFM16S201 is a Cabled Connector in the Modicon Quantum range from Schneider Electric. It is engineered for industrial automation duties within the Modicon Quantum ecosystem.
Application & Technical Notes
As a cabled connector, the ABFM16S201 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Quantum equipment is installed. It performs a defined automation function within the control system and is selected to match the installed Schneider Electric platform.
Key published characteristics include an operating temperature range of –20 °C to +60 °C. These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (–20 °C to +60 °C); do not exceed it during commissioning or in enclosed panels without airflow. Inspect terminals and connectors for corrosion or looseness, and confirm the module seats correctly in its carrier. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the ABFM16S201, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm mechanical and electrical compatibility with your Modicon Quantum installation and the intended function. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the ABFM16S201?
The ABFM16S201 is a cabled connector in the Modicon Quantum range from Schneider Electric. It is described by the manufacturer as: Cabled Connector.
What are the key technical ratings of the ABFM16S201?
Its published highlights include operating temperature –20 °C to +60 °C. Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the ABFM16S201 mounted or installed?
Installation follows the standard Modicon Quantum mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the ABFM16S201 compatible with my controller?
It is part of the Modicon Quantum family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the ABFM16S201?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The ABFM16S201 from the Modicon Quantum series by Schneider Electric is a specialized cabled connector designed for reliable analogue input transmission. This unit operates effectively across various temperatures and features two connectors, ensuring robust electrical connectivity.
Description
| Note | The Schneider Electric ABFM16S201 is a cabled connector from the Modicon Quantum series, designed specifically for analogue input applications. With an impressive 16 channels, this connector ensures efficient signal transfer in various industrial settings. It offers a generous cable length of 6.6 feet (2 meters), providing adequate flexibility for installation. The device employs a dual connector system for reliable electrical connections. Its wiring adheres to AWG 24 specifications, allowing it to handle current ratings of up to 1 ampere and operates effectively at voltage levels up to 250 volts. The SUB-D connector type features 25 ways, ensuring compatibility with various devices. Constructed from multi-conductor shielded cable, the ABFM16S201 is designed to minimize interference, making it ideal for sensitive analogue signals. It is insulated with PVC, which enhances durability and provides protection from environmental factors. The operational temperature range of this connector spans from –20 °C to +60 °C, allowing for a wide range of working conditions. Weighing in at 0.62 kg, this connector is robust yet manageable, making installation straightforward and hassle-free. |
|---|---|
| Range of Product | Modicon Quantum Accessory / separate part designation Cabled connector Accessory / Separate Part Type Connector |
| Accessory / separate part category | Connection accessories Accessory / separate part destination Modicon Quantum PLC |
| Number of Channels | 16 |
Complementary
| Product Compatibility | 140ACI04000 Cable length 6.6 ft (2 m) |
|---|---|
| Type of signal | Analogue input |
| Electrical Connection | 2 connectors |
| Connector Type | SUB-D |
| Number of ways | 25 ways |
| Wire section | 0.0003 in² (0.22 mm²) |
| AWG Gauge | AWG 24 |
| Net Weight | 1.37 lb(US) (0.62 kg) |
Ordering and shipping details
| Category | US10CP222375 |
|---|---|
| Discount Schedule | 0CP2 GTIN 3389110956580 |
| Returnability | No |
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
