170XTS00900
Schneider Electric
Overview
The 170XTS00900 is a Terminal Connector Kit in the Modicon Momentum range from Schneider Electric. It is engineered for industrial automation duties within the Modicon 170 ecosystem.
Application & Technical Notes
As a terminal connector kit, the 170XTS00900 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon 170 equipment is installed. It performs a defined automation function within the control system and is selected to match the installed Schneider Electric platform.
Specific electrical and mechanical ratings depend on the exact configuration and suffix of the part; the original datasheet should be consulted for the definitive specification.
Maintenance & Diagnostics
Inspect terminals and connectors for corrosion or looseness, and confirm the module seats correctly in its carrier. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 170XTS00900, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm mechanical and electrical compatibility with your Modicon 170 installation and the intended function. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 170XTS00900?
The 170XTS00900 is a terminal connector kit in the Modicon Momentum range from Schneider Electric. It is described by the manufacturer as: Terminal Connector Kit.
What are the key technical ratings of the 170XTS00900?
The definitive ratings depend on the exact configuration; consult the original datasheet or the source PDF linked on this page for the complete table.
How is the 170XTS00900 mounted or installed?
Installation follows the standard Modicon 170 mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the 170XTS00900 compatible with my controller?
It is part of the Modicon 170 family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 170XTS00900?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The 170XTS00900 from Schneider Electric is a terminal connector kit within the Modicon Momentum series. This compact component is designed for various industrial applications, ensuring high reliability with its compliance to CE standards.
Description
| Note | Part number 170XTS00900, this terminal connector kit by Schneider Electric's Modicon Momentum series is engineered for robust connections in industrial settings. The dimensions of this connector kit are 1.18 inches in height, 3.94 inches in width, and 5.43 inches in length, contributing to its compact design. It weighs a mere 54 grams, which facilitates easy handling and installation. This component adheres to CE standards, ensuring quality and safety throughout its operation. The natural cooling method used is suitable for maintaining performance within specified temperature ranges. The connector kit supports a minimum operational temperature of 0 degrees Celsius and can function up to a maximum ambient temperature of 60 degrees Celsius. It is also designed to cope with high humidity, allowing for levels up to 95% in both operational and storage environments, as long as it is non-condensing. Additionally, the kit is capable of functioning effectively at elevations up to 1000 meters above sea level, making it versatile for various installations. Overall, the 170XTS00900 terminal connector kit is a reliable choice for establishing secure electrical connections in diverse industrial applications. Accessory / separate part designation Interbus 9-way connector kit Accessory / Separate Part Type Interbus connector kit |
|---|---|
| Accessory / separate part category | Connection accessories Accessory / separate part destination Remote bus cable |
Complementary
| Range Compatibility | Modicon Quantum automation platform Modicon Premium automation platform Kit composition 1 SUB-D 9 male connector 1 SUB-D 9 female connector |
|---|---|
| Net Weight | 0.099 lb(US) (0.045 kg) |
Ordering and shipping details
| Category | US1PC3118206 |
|---|---|
| Discount Schedule | PC31 GTIN 3389110886849 |
| Returnability | No |
Packing Units
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 1.181 in (3.000 cm) |
| Package 1 Width | 3.937 in (10.000 cm) |
| Package 1 Length | 5.433 in (13.800 cm) |
| Package weight(Lbs) | 1.905 oz (54.000 g) |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 100 |
| Package 2 Height | 11.811 in (30.000 cm) |
| Package 2 Width | 15.748 in (40.000 cm) |
| Package 2 Length | 23.622 in (60.000 cm) |
| Package 2 Weight | 13.007 lb(US) (5.900 kg) |
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
