140NOE35100
Schneider Electric
Overview
The 140NOE35100 is an Ethernet Module in the Modicon Quantum range from Schneider Electric. It extends Modicon Quantum connectivity through its onboard communication interface.
Application & Technical Notes
As an ethernet module, the 140NOE35100 is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Quantum equipment is installed. It bridges the controller to higher-level networks, HMIs, SCADA and peer devices, carrying configuration, process data and diagnostics.
Key published characteristics include a 115 to 230 Volts AC or 24 Volts DC rating, an operating temperature range of 0 to 60°C (in a non-condensing environment). These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (0 to 60°C (in a non-condensing environment)); do not exceed it during commissioning or in enclosed panels without airflow. Avoid condensation — the rated humidity is Tolerance 0% to 95% relative humidity (without condensation); store and operate the module in a dry, pollution-degree-appropriate enclosure. Confirm network addressing, baud/rate and topology match the rest of the system; keep firmware consistent across the cell. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 140NOE35100, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Match the protocol, connector and topology to the rest of the Modicon Quantum network and to the peer devices already installed. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 140NOE35100?
The 140NOE35100 is an ethernet module in the Modicon Quantum range from Schneider Electric. It is described by the manufacturer as: Ethernet Module.
What are the key technical ratings of the 140NOE35100?
Its published highlights include 115 to 230 Volts AC or 24 Volts DC, operating temperature 0 to 60°C (in a non-condensing environment). Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the 140NOE35100 mounted or installed?
Installation follows the standard Modicon Quantum mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the 140NOE35100 compatible with my controller?
It is part of the Modicon Quantum family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 140NOE35100?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The Modicon Quantum 140NOE35100 Ethernet module manufactured by Schneider Electric is designed for seamless integration in various control environments. This device features a singular communication channel, utilizing fiber optic cabling, and supports two 10BASE-FL Ethernet (ST-style) ports for robust connectivity.
Description
| Note | The 140NOE35100 from Schneider Electric falls within the Modicon Quantum series and functions as a dedicated Ethernet module. It encompasses one channel and is reliant on fiber optic cable systems for its communication. Designed for flexibility, the module includes two ports for 10BASE-FL Ethernet connections in ST style, facilitating reliable data transfer within industrial networks. For operational efficiency, the Ethernet port mandates a bus current of 1 Ampere. Protective conformal coating is applied to safeguard the unit in various environments. Notably, this module is limited to local backplane support, ensuring focused connectivity. In terms of compliance, it meets the rigorous standards outlined by UL, c-UL, CE, and CSA, attesting to its safety and reliability in diverse applications. The powered module operates efficiently under voltage conditions of 115 to 230 Volts AC or 24 Volts DC. The operating temperature for this device falls between 0 to 60°C, specifically within non-condensing conditions. Additionally, it can withstand relative humidity levels ranging from 0% to 95%, making it suitable for a variety of climates. Its operational altitude can reach up to 6,561.68 feet (2,000 meters) above sea level, expanding its applicability in various installations and environments. |
|---|
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
