140DDI35310C
Schneider Electric
Overview
The 140DDI35310C is a Low voltage dc discrete input modules in the Modicon Quantum automation platform range from Schneider Electric. It is engineered for industrial automation duties within the Modicon Quantum ecosystem.
Application & Technical Notes
As a low voltage dc discrete input modules, the 140DDI35310C is intended for deployment in panel-based control cabinets and machine enclosures where Modicon Quantum equipment is installed. It converts field signals (sensors, switches, transmitters) into the digital or analogue values the controller processes, forming the acquisition layer of the automation scheme.
Key published characteristics include a 24 V DC rating, an operating temperature range of 32…140 °F (0…60 °C). These values should be confirmed against the current manufacturer datasheet before final selection, as options and suffixes vary by configuration.
Maintenance & Diagnostics
Respect the published operating temperature window (32…140 °F (0…60 °C)); do not exceed it during commissioning or in enclosed panels without airflow. For storage and transit, keep the unit within -40…185 °F (-40…85 °C). Avoid condensation — the rated humidity is 95 % without condensation; store and operate the module in a dry, pollution-degree-appropriate enclosure. Verify field wiring, shielding and grounding at installation; check terminal torque and confirm signal types match the configured range. Periodically inspect for loose terminations, induced noise and channel-level diagnostics reported by the controller. Always de-energise the circuit and follow lock-out/tag-out before handling; refer to the official instruction bulletin for service procedures.
Sourcing & Procurement
When sourcing the 140DDI35310C, distinguish three supply tiers: (1) genuine Schneider Electric stock from an authorised distributor; (2) compatible equivalents or surplus/NOS (new-old-stock) from third parties; (3) alternative parts offering equivalent function. Genuine supply carries the full warranty and traceability; compatible or alternative items may be cheaper but should be validated for form, fit, firmware and certification before use in a live system. PLCXpert publishes this page as an independent reference and does not sell the part — verify every claim with the manufacturer or your distributor.
Confirm the module matches your Modicon Quantum rack, the required channel count, signal type and voltage, and the firmware/configuration of the controller. Lead times and pricing vary by region and lifecycle status; obtain a current quote from an authorised channel rather than relying on stale listings.
Frequently Asked Questions
What is the 140DDI35310C?
The 140DDI35310C is a low voltage dc discrete input modules in the Modicon Quantum automation platform range from Schneider Electric. It is described by the manufacturer as: Low voltage dc discrete input modules.
What are the key technical ratings of the 140DDI35310C?
Its published highlights include 24 V DC, operating temperature 32…140 °F (0…60 °C). Full electrical, mechanical and environmental limits are listed in the manufacturer datasheet and should be confirmed for your exact suffix.
How is the 140DDI35310C mounted or installed?
Installation follows the standard Modicon Quantum mounting practice for this device class; refer to the installation manual for exact dimensions and torque.
Is the 140DDI35310C compatible with my controller?
It is part of the Modicon Quantum family. Confirm the specific rack, firmware revision, slot rules and configuration with the controller documentation before purchase, as compatibility depends on the exact system build.
What should I check before buying the 140DDI35310C?
Verify the genuine part number and suffix, confirm it matches your platform and ratings, check the current lifecycle/availability status, and buy from an authorised distributor. PLCXpert provides this reference only and does not sell the component.
Specifications
The 140DDI35310C from Schneider Electric is a discrete input module designed for use in Modicon Quantum applications. It features 32 input channels with a 24 V DC input voltage. Designed for demanding environments, this module operates effectively up to a temperature of 60 °C.
Description
| Note | Schneider Electric’s 140DDI35310C is classified as a discrete input module specifically within the Modicon Quantum series. This component possesses 32 individual input channels, permitting extensive data monitoring and control capabilities. Designed to operate with a voltage of 24 V DC, this module ensures reliable performance across a wide range of industrial applications. Addressing requirements are straightforward since two input words are needed for optimal operation. The input impedance is specified at 2400 Ohm, which can facilitate diverse applications efficiently. The module supports a maximum leakage current of 200 mA and requires a bus current of 330 mA to function properly. A resistor is used to provide input protection, adding an additional layer of safety for both the module and the connected devices. The unit weighs 0.3 kg, making it manageable for installations. Furthermore, it is suitable for ambient temperatures from 0 to 60 °C, which defines its operational versatility in varied environment conditions. Protective treatment through conformal coating offers resistance against moisture and dust, enhancing durability in industrial settings. This module also meets several industry standards, including UL 508 and CSA, further asserting its reliability. Lastly, it carries the CE marking, indicating compliance with EU safety standards. |
|---|---|
| Range of Product | Modicon Quantum automation platform Product or Component Type Low voltage dc discrete input modules Discrete input number 32 |
Complementary
| Group of channels | 4 |
|---|---|
| Logic input | Negative (source) |
| Discrete input voltage | 24 V DC |
| Input voltage limits | 19.2...30 V |
| Voltage state 1 guaranteed | -30...-15 V DC |
| Voltage state 0 guaranteed | -5...0 V DC |
| Current state 1 guaranteed | >= 2.5 mA at Us = - 14 V |
| Current state 0 guaranteed | <= 0.5 mA |
| Addressing requirement | 2 input words |
| Input impedance | 2400 Ohm |
| Maximum leakage current | 200 mA at Us = 5.5 V and Uin = 4 V |
| Absolute maximum input | 30 V continuous 50 V during 1 ms decaying pulse |
| Response Time | <= 1 ms from state 0 to state 1 <= 1 ms from state 1 to state 0 |
| Protection Type | Input protection by resistor limited |
| Power dissipation | 1.5 W + (0.26 x number of points on) |
| Isolation between group and bus | 1780 Vrms for 1 minute |
| Isolation between group | 500 Vrms for 1 minute |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 32 LEDs (green) for input status |
| Marking | CE |
| Bus current requirement | 330 mA |
| Module format | Standard |
| Net Weight | 0.7 lb(US) (0.3 kg) |
Environment
| Protective treatment | Conformal coating Humiseal 1A33 |
|---|---|
| Standards | N/A |
| CSA C22.2 No 142 | UL 508 |
| Product Certifications | RINA GOST |
| C-tick | FM Class 1 Division 2 RMRS |
| Resistance to electrostatic discharge | 4 kV contact IEC 801-2 8 kV on air IEC 801-2 |
| Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3 |
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
| Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Relative Humidity | 95 % without condensation |
| Operating altitude | <= 16404.2 ft (5000 m) |
Ordering and shipping details
| Category | 18155-QUANTUM I/O & POWER SUPPLIES |
|---|---|
| Discount Schedule | PC21 GTIN 3595861137134 |
| Returnability | No |
| Country of origin | CN |
Packing Units
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 6.4 in (16.3 cm) |
| Package 1 Width | 1.8 in (4.5 cm) |
| Package 1 Length | 12.3 in (31.2 cm) |
| Package weight(Lbs) | 15.3 oz (435 g) |
Reproduced from the manufacturer's published data. Values marked "Not available" are absent from the source document.
